ABC Seamless Metal Roofing Coil Material Specifications

METAL

28-gauge galvanized L.F.Q. with both sides
zinc coated by continuous method.

PAINT PREPARATION

Both sides of substrate chemically cleaned with an alkaline
“Parco 338W” cleaner. Dry in place chrome conversion coating
with Henkel “1402W Bonderite” applied to both sides of substrate.

Rating	Results
FM-4470 Foot Traffic/Hail Resistance	Is resistant to severe hail and foot traffic
UL-1897 Uplift Resistance	Up to 160 mph rating with 5 clips and screws
UL-22180 Hail/Impact Resistance	Class 4 rating (highest possible rating)
ICBO AC07 Penetration Resistance	200 lbs. pressure, minimum deformation
ASTM A90-95 Galvanization Performance	Meets or exceeds G90 standard
UL-790 Fire Resistance



---

ABC SEAMLESS STEEL SIDING, GUTTER, SOFFIT & FASCIA AND WINDOW WRAPS COIL MATERIAL SPECIFICATIONS

METAL

28-gauge galvanized L.F.Q. with both sides
zinc coated by continuous method.

PAINT PREPARATION

Both sides of substrate chemically cleaned with an alkaline
“Parco 338W” cleaner. Dry in place chrome conversion coating
with Henkel “1402W Bonderite” applied to both sides of substrate.

PAINT SYSTEM

Prime Coat: AZKO-Nobel Coating’s “Prime-A-Sol” corrosion
resistant primer.
Top Coat: AZKO-Nobel Coating’s chemical striated vinyl platisol
Back Coat: AZKO-Nobel Coating’s corrosion resisting backer

TENSILE STRENGTH

50,000/PSI approx. Yield Strength PSI 35,000

All materials confirm to ASTMA653-M

Teflon® is a registered trademark of DuPont used under license by ABC Inc, d/b/a ABC Seamless”
